NCP1271D100R2G
در 3 فروشگاه
| Manufacturer | ON Semiconductor |
| Package | 8-SOIC (0.154", 3.90mm Width), 7 Leads |
| Datasheet | NCP1271 |
| Description | Converter Offline Flyback Topology 100kHz 7-SOIC |
فروشگاه های اینترنتی
تغییرات قیمت
مشخصات
- Manufacturer ON Semiconductor
- Series Soft-Skip™
- Packaging Cut Tape (CT)
- Part Status Not For New Designs
- Output Isolation Isolated
- Internal Switch(s) No
- Voltage - Breakdown -
- Topology Flyback
- Voltage - Start Up 12.6V
- Voltage - Supply (Vcc/Vdd) 10V ~ 20V
- Duty Cycle 80%
- Frequency - Switching 100kHz
- Fault Protection Current Limiting, Over Load, Over Voltage, Short Circuit
- Control Features -
- Operating Temperature -40°C ~ 125°C (TJ)
- Package / Case 8-SOIC (0.154", 3.90mm Width), 7 Leads
- Supplier Device Package 7-SOIC
- Mounting Type Surface Mount
- Base Part Number NCP1271
- detail Converter Offline Flyback Topology 100kHz 7-SOIC
