مشخصات
- ON SemiconductorManufacturer
- UniFET™Series
- TubePackaging
- ActivePart Status
- N-ChannelFET Type
- MOSFET (Metal Oxide)Technology
- 500VDrain to Source Voltage (Vdss)
- 24A (Tc)Current - Continuous Drain (Id) @ 25°C
- 10VDrive Voltage (Max Rds On, Min Rds On)
- 200mOhm @ 12A, 10VRds On (Max) @ Id, Vgs
- 5V @ 250µAVgs(th) (Max) @ Id
- 85nC @ 10VGate Charge (Qg) (Max) @ Vgs
- ±30VVgs (Max)
- 4310pF @ 25VInput Capacitance (Ciss) (Max) @ Vds
- -FET Feature
- 270W (Tc)Power Dissipation (Max)
- -55°C ~ 150°C (TJ)Operating Temperature
- Through HoleMounting Type
- TO-3PNSupplier Device Package
- TO-3P-3, SC-65-3Package / Case
- FDA24Base Part Number
