مشخصات فنی:
ManufacturerON Semiconductor
PackageTO-220-3
Datasheet TO220B03 Pkg Drawing
Description N-Channel 60V 15A (Tc) 50W (Tc) Through Hole TO-220-3
تغییرات قیمت
مشخصات
  • Manufacturer ON Semiconductor
  • Series -
  • Packaging Tube
  • Part Status Obsolete
  • FET Type N-Channel
  • Technology MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss) 60V
  • Current - Continuous Drain (Id) @ 25°C 15A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On) 10V
  • Rds On (Max) @ Id, Vgs 100mOhm @ 7.5A, 10V
  • Vgs(th) (Max) @ Id 4V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs 17nC @ 10V
  • Vgs (Max) ±20V
  • Input Capacitance (Ciss) (Max) @ Vds 450pF @ 25V
  • FET Feature -
  • Power Dissipation (Max) 50W (Tc)
  • Operating Temperature -65°C ~ 175°C (TJ)
  • Mounting Type Through Hole
  • Supplier Device Package TO-220-3
  • Package / Case TO-220-3
  • Base Part Number NDP406
  • detail N-Channel 60V 15A (Tc) 50W (Tc) Through Hole TO-220-3
