مشخصات
- Manufacturer ON Semiconductor
- Series -
- Packaging Cut Tape (CT)
- Part Status Obsolete
- FET Type N-Channel
- Technology MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss) 30V
- Current - Continuous Drain (Id) @ 25°C 3.2A (Ta)
- Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
- Rds On (Max) @ Id, Vgs 60mOhm @ 4A, 10V
- Vgs(th) (Max) @ Id 3V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs 20nC @ 10V
- Vgs (Max) 20V
- Input Capacitance (Ciss) (Max) @ Vds 290pF @ 15V
- FET Feature -
- Power Dissipation (Max) 1.6W (Ta)
- Operating Temperature -55°C ~ 150°C (TJ)
- Mounting Type Surface Mount
- Supplier Device Package SuperSOT™-6
- Package / Case SOT-23-6 Thin, TSOT-23-6
- Base Part Number NDC651
- detail N-Channel 30V 3.2A (Ta) 1.6W (Ta) Surface Mount SuperSOT™-6
