NTMS3P03R2

NTMS3P03R2

NTMS3P03R2

در 2 فروشگاه

مشخصات فنی:
ManufacturerON Semiconductor
Package8-SOIC (0.154", 3.90mm Width)
Datasheet NTMS3P03R2
Description P-Channel 30V 2.34A (Ta) 730mW (Ta) Surface Mount 8-SOIC
تغییرات قیمت
مشخصات
  • Manufacturer ON Semiconductor
  • Series -
  • Packaging Tape & Reel (TR)
  • Part Status Obsolete
  • FET Type P-Channel
  • Technology MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss) 30V
  • Current - Continuous Drain (Id) @ 25°C 2.34A (Ta)
  • Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
  • Rds On (Max) @ Id, Vgs 85mOhm @ 3.05A, 10V
  • Vgs(th) (Max) @ Id 2.5V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs 25nC @ 10V
  • Vgs (Max) ±20V
  • Input Capacitance (Ciss) (Max) @ Vds 750pF @ 24V
  • FET Feature -
  • Power Dissipation (Max) 730mW (Ta)
  • Operating Temperature -55°C ~ 150°C (TJ)
  • Mounting Type Surface Mount
  • Supplier Device Package 8-SOIC
  • Package / Case 8-SOIC (0.154", 3.90mm Width)
  • Base Part Number NTMS3P
  • detail P-Channel 30V 2.34A (Ta) 730mW (Ta) Surface Mount 8-SOIC
