FGH50N6S2

FGH50N6S2

FGH50N6S2

در 2 فروشگاه

مشخصات فنی:
ManufacturerON Semiconductor
PackageTO-247-3
Datasheet Plating Material 20/Dec/2007
Description ---
تغییرات قیمت
مشخصات
  • Manufacturer ON Semiconductor
  • Series -
  • Packaging Tube
  • Part Status Obsolete
  • IGBT Type -
  • Voltage - Collector Emitter Breakdown (Max) 600V
  • Current - Collector (Ic) (Max) 75A
  • Current - Collector Pulsed (Icm) 240A
  • Vce(on) (Max) @ Vge, Ic 2.7V @ 15V, 30A
  • Power - Max 463W
  • Switching Energy 260µJ (on), 250µJ (off)
  • Input Type Standard
  • Gate Charge 70nC
  • Td (on/off) @ 25°C 13ns/55ns
  • Test Condition 390V, 30A, 3Ohm, 15V
  • Operating Temperature -55°C ~ 150°C (TJ)
  • Mounting Type Through Hole
  • Package / Case TO-247-3
  • Supplier Device Package TO-247-3
  • Base Part Number FGH50
