NDP6030PL

NDP6030PL

NDP6030PL

در 3 فروشگاه

مشخصات فنی:
ManufacturerON Semiconductor
PackageTO-220-3
Datasheet TO220B03 Pkg Drawing
Description P-Channel 30V 30A (Tc) 75W (Tc) Through Hole TO-220-3
تغییرات قیمت
مشخصات
  • Manufacturer ON Semiconductor
  • Series -
  • Packaging Tube
  • Part Status Obsolete
  • FET Type P-Channel
  • Technology MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss) 30V
  • Current - Continuous Drain (Id) @ 25°C 30A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
  • Rds On (Max) @ Id, Vgs 25mOhm @ 19A, 10V
  • Vgs(th) (Max) @ Id 2V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs 36nC @ 5V
  • Vgs (Max) ±16V
  • Input Capacitance (Ciss) (Max) @ Vds 1570pF @ 15V
  • FET Feature -
  • Power Dissipation (Max) 75W (Tc)
  • Operating Temperature -65°C ~ 175°C (TJ)
  • Mounting Type Through Hole
  • Supplier Device Package TO-220-3
  • Package / Case TO-220-3
  • Base Part Number NDP603
  • detail P-Channel 30V 30A (Tc) 75W (Tc) Through Hole TO-220-3
