FDS4935BZ
در 1 فروشگاه قیمت هنوز مشخص نشده است
| Manufacturer | onsemi |
| Package | 8-SOIC (0.154", 3.90mm Width) |
| Datasheet | FDS4935BZ |
| Description | Mosfet Array 2 P-Channel (Dual) 30V 6.9A 900mW Surface Mount 8-SOIC |
فروشنده های FDS4935BZ
| قیمت | |||
| FDS4935BZ | ناموجود بدون قیمت |
خرید اینترنتی
آخرین تغییر قیمت فروشگاه:
|
تغییرات قیمت
مشخصات FDS4935BZ
- RoHS true
- Type 2 P-Channel
- Category Triode/MOS Tube/Transistor/MOSFETs
- Datasheet onsemi FDS4935BZ
- Operating Temperature -55°C~+150°C@(Tj)
- Power Dissipation (Pd) 900mW
- Total Gate Charge (Qg@Vgs) 40nC@10V
- Drain Source Voltage (Vdss) 30V
- Input Capacitance (Ciss@Vds) 1360pF@15V
- Continuous Drain Current (Id) 6.9A
- Gate Threshold Voltage (Vgs(th)@Id) 3V@250uA
- Drain Source On Resistance (RDS(on)@Vgs,Id) 22mΩ@10V,6.9A
- Package SOP-8
- Manufacturer onsemi
- Series PowerTrench®
- Packaging Cut Tape (CT)
- Part Status Active
- FET Type 2 P-Channel (Dual)
- FET Feature Logic Level Gate
- Drain to Source Voltage (Vdss) 30V
- Current - Continuous Drain (Id) @ 25°C 6.9A
- Rds On (Max) @ Id, Vgs 22mOhm @ 6.9A, 10V
- Vgs(th) (Max) @ Id 3V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs 40nC @ 10V
- Input Capacitance (Ciss) (Max) @ Vds 1360pF @ 15V
- Power - Max 900mW
- Mounting Type Surface Mount
- Package / Case 8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package 8-SOIC
- Base Part Number FDS49
- detail Mosfet Array 2 P-Channel (Dual) 30V 6.9A 900mW Surface Mount 8-SOIC
