مشخصات STL160NS3LLH7
- Manufacturer STMicroelectronics
- Series DeepGATE™, STripFET™ VII
- Packaging Cut Tape (CT)
- Part Status Obsolete
- FET Type N-Channel
- Technology MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss) 30V
- Current - Continuous Drain (Id) @ 25°C 160A (Tc)
- Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
- Rds On (Max) @ Id, Vgs 2.1mOhm @ 18A, 10V
- Vgs(th) (Max) @ Id 2.3V @ 1mA
- Gate Charge (Qg) (Max) @ Vgs 20nC @ 4.5V
- Vgs (Max) ±20V
- Input Capacitance (Ciss) (Max) @ Vds 3245pF @ 25V
- FET Feature -
- Power Dissipation (Max) 84W (Tc)
- Operating Temperature -55°C ~ 150°C (TJ)
- Mounting Type Surface Mount
- Supplier Device Package PowerFlat™ (5x6)
- Package / Case 8-PowerVDFN
- Base Part Number STL160
- detail N-Channel 30V 160A (Tc) 84W (Tc) Surface Mount PowerFlat™ (5x6)
