ADG508AKNZ

ADG508AKNZ

ADG508AKNZ

1 Circuit IC Switch 8:1 300Ohm 16-PDIP

در 3 فروشگاه

تغییرات قیمت
مشخصات
  • Analog Devices Inc.Manufacturer
  • -Series
  • TubePackaging
  • ActivePart Status
  • -Switch Circuit
  • 8:1Multiplexer/Demultiplexer Circuit
  • 1Number of Circuits
  • 300OhmOn-State Resistance (Max)
  • 15OhmChannel-to-Channel Matching (ΔRon)
  • 10.8V ~ 16.5VVoltage - Supply, Single (V+)
  • ±10.8V ~ 16.5VVoltage - Supply, Dual (V±)
  • 300ns, 300nsSwitch Time (Ton, Toff) (Max)
  • --3db Bandwidth
  • 4pCCharge Injection
  • 5pF, 22pFChannel Capacitance (CS(off), CD(off))
  • 1nACurrent - Leakage (IS(off)) (Max)
  • -Crosstalk
  • -40°C ~ 85°C (TA)Operating Temperature
  • Through HoleMounting Type
  • 16-DIP (0.300", 7.62mm)Package / Case
  • 16-PDIPSupplier Device Package
  • ADG508Base Part Number
