دیتاشیت MAX328CPE*

MAX328,329

مشخصات دیتاشیت

نام دیتاشیت MAX328,329
حجم فایل 173.549 کیلوبایت
نوع فایل pdf
تعداد صفحات 10

دانلود دیتاشیت MAX328,329

MAX328,329 Datasheet

مشخصات

  • Multiplexer/Demultiplexer Circuit: 8:1
  • Part Status: Obsolete
  • Charge Injection: 2pC
  • -3db Bandwidth: -
  • Operating Temperature: 0°C ~ 70°C (TA)
  • Voltage - Supply, Dual (V±): ±5V ~ 18V
  • Supplier Device Package: 16-PDIP
  • Package / Case: 16-DIP (0.300", 7.62mm)
  • Switch Time (Ton, Toff) (Max): 1.5µs, 1µs
  • Packaging: Tube
  • Channel-to-Channel Matching (ΔRon): 70Ohm
  • Voltage - Supply, Single (V+): 10V ~ 30V
  • Channel Capacitance (CS(off), CD(off)): 1.8pF, 8pF
  • Switch Circuit: -
  • Mounting Type: Through Hole
  • Series: -
  • Crosstalk: -
  • Number of Circuits: 1
  • Manufacturer: Maxim Integrated
  • Current - Leakage (IS(off)) (Max): 10pA
  • Base Part Number: MAX328
  • On-State Resistance (Max): 3.5kOhm
  • detail: 1 Circuit IC Switch 8:1 3.5kOhm 16-PDIP
