FDV304P دیتاشیت

FDV304P

مشخصات دیتاشیت

نام دیتاشیت FDV304P
حجم فایل 62.095 کیلوبایت
نوع فایل pdf
تعداد صفحات 4

مشاهده دیتاشیت FDV304P

دانلود دیتاشیت

سایر مستندات

FDV304P 5 pages

مشخصات فنی

  • RoHS: true
  • Type: P Channel
  • Category: Triode/MOS Tube/Transistor/MOSFETs
  • Datasheet: onsemi FDV304P
  • Operating Temperature: -55°C~+150°C@(Tj)
  • Power Dissipation (Pd): 350mW
  • Total Gate Charge (Qg@Vgs): 1.5nC@4.5V
  • Drain Source Voltage (Vdss): 25V
  • Input Capacitance (Ciss@Vds): 63pF@10V
  • Continuous Drain Current (Id): 460mA
  • Gate Threshold Voltage (Vgs(th)@Id): 1.5V@250uA
  • Drain Source On Resistance (RDS(on)@Vgs,Id): 1.1Ω@4.5V,500mA
  • Package: SOT-23(TO-236)
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • FET Type: P-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 25V
  • Current - Continuous Drain (Id) @ 25°C: 460mA (Ta)
  • Drive Voltage (Max Rds On, Min Rds On): 2.7V, 4.5V
  • Rds On (Max) @ Id, Vgs: 1.1Ohm @ 500mA, 4.5V
  • Vgs(th) (Max) @ Id: 1.5V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 1.5nC @ 4.5V
  • Vgs (Max): ±8V
  • Input Capacitance (Ciss) (Max) @ Vds: 63pF @ 10V
  • FET Feature: -
  • Power Dissipation (Max): 350mW (Ta)
  • Mounting Type: Surface Mount
  • Supplier Device Package: SOT-23
  • Package / Case: TO-236-3, SC-59, SOT-23-3
  • Base Part Number: FDV30
  • detail: P-Channel 25V 460mA (Ta) 350mW (Ta) Surface Mount SOT-23
