دیتاشیت MAX4734EUB+T MSOP10

MAX4734

مشخصات دیتاشیت

نام دیتاشیت MAX4734
حجم فایل 1591.646 کیلوبایت
نوع فایل pdf
تعداد صفحات 12

دانلود دیتاشیت MAX4734

MAX4734 Datasheet

مشخصات

  • Multiplexer/Demultiplexer Circuit: 4:1
  • Part Status: Active
  • Charge Injection: 60pC
  • -3db Bandwidth: 90MHz
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Voltage - Supply, Dual (V±): -
  • Supplier Device Package: 10-uMAX
  • Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
  • Switch Time (Ton, Toff) (Max): 25ns, 20ns
  • Packaging: Cut Tape (CT)
  • Channel-to-Channel Matching (ΔRon): 100mOhm
  • Voltage - Supply, Single (V+): 1.6V ~ 3.6V
  • Channel Capacitance (CS(off), CD(off)): 33pF, 117pF
  • Switch Circuit: SP4T
  • Mounting Type: Surface Mount
  • Series: -
  • Crosstalk: -56dB @ 1MHz
  • Number of Circuits: 1
  • Manufacturer: Maxim Integrated
  • Current - Leakage (IS(off)) (Max): 1nA
  • Base Part Number: MAX4734
  • On-State Resistance (Max): 800mOhm
  • detail: 1 Circuit IC Switch 4:1 800mOhm 10-uMAX
