دیتاشیت SN74LVC1G3157DBVR CODE:CC5 SOT-23-6 SOT-363 آی سی سوییچ آنالوگ
مشخصات دیتاشیت
| نام دیتاشیت | SN74LVC1G3157 Datasheet |
|---|---|
| حجم فایل | 3077.749 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 45 |
دانلود دیتاشیت SN74LVC1G3157 Datasheet |
SN74LVC1G3157 Datasheet Datasheet |
|---|
مشخصات
- Manufacturer: Texas Instruments
- Package / Case: SOT-23-6
- Series: -
- Switch Time (Ton, Toff) (Max): 5.7ns, 3.8ns
- Supplier Device Package: SOT-23-6
- Channel Capacitance (CS(off), CD(off)): 5.2pF
- Number of Circuits: 1
- Channel-to-Channel Matching (ΔRon): 100mOhm
- -3db Bandwidth: 340MHz
- Charge Injection: 7pC
- Multiplexer/Demultiplexer Circuit: 2:1
- Packaging: Cut Tape (CT)
- Voltage - Supply, Single (V+): 1.65V ~ 5.5V
- Voltage - Supply, Dual (V±): -
- Base Part Number: SN74LVC1G
- On-State Resistance (Max): 15Ohm
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Current - Leakage (IS(off)) (Max): 1µA
- Crosstalk: -54dB @ 10MHz
- Part Status: Active
- Switch Circuit: SPDT
- detail: 1 Circuit IC Switch 2:1 15Ohm SOT-23-6
