دیتاشیت FDC6506P (HIGH COPY)
مشخصات دیتاشیت
| نام دیتاشیت | FDC6506P |
|---|---|
| حجم فایل | 169.772 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 5 |
دانلود دیتاشیت FDC6506P |
FDC6506P Datasheet |
|---|
مشخصات
- Manufacturer: ON Semiconductor
- Series: PowerTrench®
- Packaging: Cut Tape (CT)
- Part Status: Active
- FET Type: 2 P-Channel (Dual)
- FET Feature: Logic Level Gate
- Drain to Source Voltage (Vdss): 30V
- Current - Continuous Drain (Id) @ 25°C: 1.8A
- Rds On (Max) @ Id, Vgs: 170mOhm @ 1.8A, 10V
- Vgs(th) (Max) @ Id: 3V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs: 3.5nC @ 10V
- Input Capacitance (Ciss) (Max) @ Vds: 190pF @ 15V
- Power - Max: 700mW
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: SOT-23-6 Thin, TSOT-23-6
- Supplier Device Package: SuperSOT™-6
- Base Part Number: FDC6506
- detail: Mosfet Array 2 P-Channel (Dual) 30V 1.8A 700mW Surface Mount SuperSOT™-6
