دیتاشیت MAX4754ETE+T

MAX4754/54A/55-56/56A

مشخصات دیتاشیت

نام دیتاشیت MAX4754/54A/55-56/56A
حجم فایل 324.507 کیلوبایت
نوع فایل pdf
تعداد صفحات 15

دانلود دیتاشیت MAX4754/54A/55-56/56A

MAX4754/54A/55-56/56A Datasheet

مشخصات

  • Multiplexer/Demultiplexer Circuit: 2:1
  • Part Status: Discontinued at Digi-Key
  • Charge Injection: 300pC
  • -3db Bandwidth: 10MHz
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Voltage - Supply, Dual (V±): -
  • Supplier Device Package: 16-TQFN (4x4)
  • Package / Case: 16-WQFN Exposed Pad
  • Switch Time (Ton, Toff) (Max): 140ns, 50ns
  • Packaging: Cut Tape (CT)
  • Channel-to-Channel Matching (ΔRon): 100mOhm
  • Voltage - Supply, Single (V+): 1.8V ~ 5.5V
  • Channel Capacitance (CS(off), CD(off)): 180pF, 300pF
  • Switch Circuit: SPDT
  • Mounting Type: Surface Mount
  • Series: -
  • Crosstalk: -90dB @ 100kHz
  • Number of Circuits: 4
  • Manufacturer: Maxim Integrated
  • Current - Leakage (IS(off)) (Max): 4nA
  • Base Part Number: MAX4754
  • On-State Resistance (Max): 850mOhm
  • detail: 4 Circuit IC Switch 2:1 850mOhm 16-TQFN (4x4)
