Part Numbering System Datasheet

Part Numbering System

Datasheet specifications

Datasheet's name Part Numbering System
File size 107.748 KB
File type pdf
Number of pages 7

Download Datasheet Part Numbering System

Download Datasheet

Other documentations

MAX1108/09 20 pages

MAX1108CUB+T 20 pages

Technical specifications

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
  • Datasheet: Analog Devices Inc./Maxim Integrated MAX1109CUB+T
  • Interface: SPI
  • resolution: 8
  • Supply Voltage: 5V
  • number of channels: 2
  • sampling frequency: 50kHz
  • Operating Temperature: 0°C~+70°C
  • Package: UMAX-10
  • Manufacturer: Analog Devices Inc./Maxim Integrated
  • Part Status: Active
  • Data Interface: SPI
  • Voltage - Supply, Digital: 5V
  • Sampling Rate (Per Second): 50k
  • Architecture: SAR
  • Supplier Device Package: 10-uMAX
  • Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
  • Number of A/D Converters: 1
  • Packaging: Tape & Reel (TR)
  • Features: -
  • Configuration: MUX-S/H-ADC
  • Ratio - S/H:ADC: 1:1
  • Input Type: Pseudo-Differential, Single Ended
  • Reference Type: External, Internal
  • Number of Bits: 8
  • Mounting Type: Surface Mount
  • Series: -
  • Voltage - Supply, Analog: 5V
  • Number of Inputs: 2
  • Base Part Number: MAX1109
  • detail: 8 Bit Analog to Digital Converter 2 Input 1 SAR 10-uMAX
