دیتاشیت MAX4712CUE+T
مشخصات دیتاشیت
| نام دیتاشیت |
MAX4711-13
|
| حجم فایل |
916.018
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
17
|
مشخصات
-
Multiplexer/Demultiplexer Circuit:
1:1
-
Part Status:
Active
-
Charge Injection:
25pC
-
-3db Bandwidth:
-
-
Operating Temperature:
0°C ~ 70°C (TA)
-
Voltage - Supply, Dual (V±):
±2.7V ~ 5.5V
-
Supplier Device Package:
16-TSSOP
-
Package / Case:
16-TSSOP (0.173", 4.40mm Width)
-
Switch Time (Ton, Toff) (Max):
125ns, 80ns
-
Packaging:
Tube
-
Channel-to-Channel Matching (ΔRon):
200mOhm
-
Voltage - Supply, Single (V+):
2.7V ~ 11V
-
Channel Capacitance (CS(off), CD(off)):
8pF, 8pF
-
Switch Circuit:
SPST - NO
-
Mounting Type:
Surface Mount
-
Series:
-
-
Crosstalk:
-87dB @ 1MHz
-
Number of Circuits:
4
-
Manufacturer:
Maxim Integrated
-
Current - Leakage (IS(off)) (Max):
500pA
-
Base Part Number:
MAX4712
-
On-State Resistance (Max):
25Ohm
-
detail:
4 Circuit IC Switch 1:1 25Ohm 16-TSSOP
