دیتاشیت MAX1971EEE+T

MAX1970-72

مشخصات دیتاشیت

نام دیتاشیت MAX1970-72
حجم فایل 278.355 کیلوبایت
نوع فایل pdf
تعداد صفحات 21

دانلود دیتاشیت MAX1970-72

MAX1970-72 Datasheet

مشخصات

  • Number of Outputs: 2
  • Function: Step-Down
  • Voltage - Input (Max): 5.5V
  • Voltage - Input (Min): 2.6V
  • Output Configuration: Positive
  • Supplier Device Package: 16-QSOP
  • Package / Case: 16-SSOP (0.154", 3.90mm Width)
  • Frequency - Switching: 700kHz
  • Current - Output: 750mA
  • Part Status: Active
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Output Type: Adjustable (Programmable)
  • Series: -
  • Voltage - Output (Max): 5.5V
  • Base Part Number: MAX1971
  • Mounting Type: Surface Mount
  • Synchronous Rectifier: Yes
  • Voltage - Output (Min/Fixed): 1.2V (1.5V, 1.8V, 2.5V, 3.3V)
  • Packaging: Tube
  • Topology: Buck
  • Manufacturer: Maxim Integrated
  • detail: Buck Switching Regulator IC Positive Adjustable (Programmable) 1.2V (1.5V, 1.8V, 2.5V, 3.3V) 2 Output 750mA 16-SSOP (0.154", 3.90mm Width)
