دیتاشیت MAX4608ESE+
مشخصات دیتاشیت
| نام دیتاشیت |
MAX4607-09
|
| حجم فایل |
161.677
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
11
|
مشخصات
-
RoHS:
true
-
Category:
Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
-
Datasheet:
Analog Devices Inc./Maxim Integrated MAX4608ESE+
-
Turn-on time:
110ns
-
Turn-off time:
150ns
-
Supply Voltage:
4.5V~36V
-
Switch Circuit:
SPST(SPST)-Normal Open
-
Number of Channels:
2
-
On-State Resistance (Max):
2.5Ω
-
Package:
SO-16
-
Manufacturer:
Analog Devices Inc./Maxim Integrated
-
Multiplexer/Demultiplexer Circuit:
1:1
-
Part Status:
Obsolete
-
Charge Injection:
45pC
-
-3db Bandwidth:
-
-
Operating Temperature:
-40°C ~ 85°C (TA)
-
Voltage - Supply, Dual (V±):
±4.5V ~ 20V
-
Supplier Device Package:
16-SOIC
-
Package / Case:
16-SOIC (0.154", 3.90mm Width)
-
Switch Time (Ton, Toff) (Max):
110ns, 150ns
-
Packaging:
Tube
-
Channel-to-Channel Matching (ΔRon):
50mOhm
-
Voltage - Supply, Single (V+):
4.5V ~ 36V
-
Channel Capacitance (CS(off), CD(off)):
64pF, 64pF
-
Mounting Type:
Surface Mount
-
Series:
-
-
Crosstalk:
-66dB @ 1MHz
-
Number of Circuits:
2
-
Current - Leakage (IS(off)) (Max):
500pA
-
Base Part Number:
MAX4608
-
detail:
2 Circuit IC Switch 1:1 2.5Ohm 16-SOIC
