دیتاشیت MAX334MJE/HR

MAX334

مشخصات دیتاشیت

نام دیتاشیت MAX334
حجم فایل 129.791 کیلوبایت
نوع فایل pdf
تعداد صفحات 4

دانلود دیتاشیت MAX334

MAX334 Datasheet

مشخصات

  • Multiplexer/Demultiplexer Circuit: 1:1
  • Part Status: Obsolete
  • Charge Injection: 10pC
  • -3db Bandwidth: -
  • Operating Temperature: -55°C ~ 125°C (TA)
  • Voltage - Supply, Dual (V±): ±5V ~ 15V
  • Supplier Device Package: 16-CERDIP
  • Package / Case: 16-CDIP (0.300", 7.62mm)
  • Switch Time (Ton, Toff) (Max): 120ns, 75ns
  • Packaging: Tube
  • Channel-to-Channel Matching (ΔRon): 1.5Ohm
  • Voltage - Supply, Single (V+): 5V ~ 30V
  • Channel Capacitance (CS(off), CD(off)): 10pF, 10pF
  • Switch Circuit: SPST - NC
  • Mounting Type: Through Hole
  • Series: -
  • Crosstalk: -86dB @ 1MHz
  • Number of Circuits: 4
  • Manufacturer: Maxim Integrated
  • Current - Leakage (IS(off)) (Max): 1nA
  • Base Part Number: MAX334
  • On-State Resistance (Max): 50Ohm
  • detail: 4 Circuit IC Switch 1:1 50Ohm 16-CERDIP
