Part Numbering System Datasheet

Part Numbering System

Datasheet specifications

Datasheet's name Part Numbering System
File size 107.748 KB
File type pdf
Number of pages 7

Download Datasheet Part Numbering System

Download Datasheet

Other documentations

MAX4644 10 pages

Technical specifications

  • Multiplexer/Demultiplexer Circuit: 2:1
  • Part Status: Obsolete
  • Charge Injection: 5pC
  • -3db Bandwidth: -
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Voltage - Supply, Dual (V±): -
  • Supplier Device Package: SOT-23-6
  • Package / Case: SOT-23-6
  • Switch Time (Ton, Toff) (Max): 15ns, 5ns
  • Packaging: Tape & Reel (TR)
  • Channel-to-Channel Matching (ΔRon): 100mOhm
  • Voltage - Supply, Single (V+): 1.8V ~ 5.5V
  • Channel Capacitance (CS(off), CD(off)): 12pF
  • Switch Circuit: SPDT
  • Mounting Type: Surface Mount
  • Series: -
  • Crosstalk: -82dB @ 1MHz
  • Number of Circuits: 1
  • Manufacturer: Maxim Integrated
  • Current - Leakage (IS(off)) (Max): 250pA
  • Base Part Number: MAX4644
  • On-State Resistance (Max): 4Ohm
  • detail: 1 Circuit IC Switch 2:1 4Ohm SOT-23-6
