Part Numbering System دیتاشیت

Part Numbering System

مشخصات دیتاشیت

نام دیتاشیت Part Numbering System
حجم فایل 107.748 کیلوبایت
نوع فایل pdf
تعداد صفحات 7

دانلود دیتاشیت Part Numbering System

دانلود دیتاشیت

سایر مستندات

MAX4947/48 13 pages

مشخصات فنی

  • Multiplexer/Demultiplexer Circuit: 2:2
  • Part Status: Active
  • Charge Injection: 10pC
  • -3db Bandwidth: 300MHz
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Voltage - Supply, Dual (V±): -
  • Supplier Device Package: 24-TQFN (4x4)
  • Package / Case: 24-WFQFN Exposed Pad
  • Switch Time (Ton, Toff) (Max): 800ns, 800ns
  • Packaging: Tube
  • Channel-to-Channel Matching (ΔRon): 300mOhm
  • Voltage - Supply, Single (V+): 1.8V ~ 5.5V
  • Channel Capacitance (CS(off), CD(off)): 15pF
  • Switch Circuit: DPDT
  • Mounting Type: Surface Mount
  • Series: -
  • Crosstalk: -90dB @ 1MHz
  • Number of Circuits: 3
  • Manufacturer: Maxim Integrated
  • Current - Leakage (IS(off)) (Max): 3nA
  • Base Part Number: MAX4947
  • On-State Resistance (Max): 5.5Ohm
  • detail: 3 Circuit IC Switch 2:2 5.5Ohm 24-TQFN (4x4)
