دیتاشیت MAX4760EBX+TW

MAX4760/60A/61/61A

مشخصات دیتاشیت

نام دیتاشیت MAX4760/60A/61/61A
حجم فایل 233.912 کیلوبایت
نوع فایل pdf
تعداد صفحات 14

دانلود دیتاشیت MAX4760/60A/61/61A

MAX4760/60A/61/61A Datasheet

مشخصات

  • Multiplexer/Demultiplexer Circuit: 2:2
  • Part Status: Obsolete
  • Charge Injection: 15pC
  • -3db Bandwidth: 150MHz
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Voltage - Supply, Dual (V±): -
  • Supplier Device Package: 36-UCSP (3x3)
  • Package / Case: 36-WFBGA, CSPBGA
  • Switch Time (Ton, Toff) (Max): 140ns, 50ns
  • Packaging: Cut Tape (CT)
  • Channel-to-Channel Matching (ΔRon): 200mOhm
  • Voltage - Supply, Single (V+): 1.8V ~ 5.5V
  • Channel Capacitance (CS(off), CD(off)): 25pF
  • Switch Circuit: DPDT
  • Mounting Type: Surface Mount
  • Series: -
  • Crosstalk: -95dB @ 100kHz
  • Number of Circuits: 4
  • Manufacturer: Maxim Integrated
  • Current - Leakage (IS(off)) (Max): 5nA
  • Base Part Number: MAX4760
  • On-State Resistance (Max): 3.5Ohm
  • detail: 4 Circuit IC Switch 2:2 3.5Ohm 36-UCSP (3x3)
