Part Numbering System Datasheet

Part Numbering System

Datasheet specifications

Datasheet's name Part Numbering System
File size 107.748 KB
File type pdf
Number of pages 7

Download Datasheet Part Numbering System

Download Datasheet

Other documentations

MAX9691-93 12 pages

Technical specifications

  • Voltage - Supply, Single/Dual (±): -
  • Voltage - Input Offset (Max): 6.5mV @ 5V
  • Hysteresis: -
  • Output Type: Complementary, ECL
  • Number of Elements: 1
  • Supplier Device Package: 8-SOIC
  • CMRR, PSRR (Typ): 80dB CMRR, 60dB PSRR
  • Propagation Delay (Max): 1.8ns
  • Part Status: Obsolete
  • Operating Temperature: -40°C ~ 85°C
  • Type: with Latch
  • Series: -
  • Current - Quiescent (Max): 26mA
  • Base Part Number: MAX9691
  • Current - Output (Typ): 50mA
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Manufacturer: Maxim Integrated
  • Packaging: Tape & Reel (TR)
  • Mounting Type: Surface Mount
  • Current - Input Bias (Max): 20µA @ 5V
  • detail: Comparator with Latch Complementary, ECL 8-SOIC
