دیتاشیت MAX5974EETE+TG3U

MAX5974E/F

مشخصات دیتاشیت

نام دیتاشیت MAX5974E/F
حجم فایل 1273.91 کیلوبایت
نوع فایل pdf
تعداد صفحات 22

دانلود دیتاشیت MAX5974E/F

MAX5974E/F Datasheet

مشخصات

  • Operating Temperature: -40°C ~ 85°C (TA)
  • Output Isolation: Non-Isolated
  • Mounting Type: Surface Mount
  • Supplier Device Package: 16-TQFN (3x3)
  • Internal Switch(s): No
  • Package / Case: 16-WFQFN Exposed Pad
  • Voltage - Start Up: 16V
  • Frequency - Switching: 100kHz ~ 600kHz
  • Part Status: Active
  • Fault Protection: Current Limiting, Over Temperature, Short Circuit
  • Series: -
  • Base Part Number: MAX5974
  • Manufacturer: Maxim Integrated
  • Duty Cycle: 80%
  • Packaging: Tape & Reel (TR)
  • Control Features: EN, Frequency Control, Soft Start, Sync
  • Voltage - Breakdown: -
  • Topology: Flyback
  • Voltage - Supply (Vcc/Vdd): 7V ~ 26V
  • detail: Converter Offline Flyback Topology 100kHz ~ 600kHz 16-TQFN (3x3)
