دیتاشیت MAX15026CETD+TG1D

مشخصات دیتاشیت

دانلود دیتاشیت MAX15026	MAX15026 Datasheet

Function: Step-Down
Part Status: Active
Output Configuration: Positive
Synchronous Rectifier: Yes
Operating Temperature: -40°C ~ 85°C (TA)
Serial Interfaces: -
Package / Case: 14-WFDFN Exposed Pad
Clock Sync: No
Output Phases: 1
Packaging: Cut Tape (CT)
Number of Outputs: 1
Voltage - Supply (Vcc/Vdd): 4.5V ~ 28V
Frequency - Switching: 200kHz ~ 2MHz
Duty Cycle (Max): 88%
Mounting Type: Surface Mount
Output Type: Transistor Driver
Series: -
Base Part Number: MAX15026
Manufacturer: Maxim Integrated
Control Features: Current Limit, Enable, Frequency Control, Power Good
Topology: Buck
Supplier Device Package: 14-TDFN-EP (3x3)
detail: Buck Regulator Positive Output Step-Down DC-DC Controller IC 14-TDFN-EP (3x3)
