دیتاشیت MAX8815AETB+TG1D
مشخصات دیتاشیت
| نام دیتاشیت |
MAX8815A
|
| حجم فایل |
336.343
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
15
|
مشخصات
-
Number of Outputs:
1
-
Function:
Step-Up
-
Voltage - Input (Max):
5.5V
-
Voltage - Input (Min):
1.2V
-
Output Configuration:
Positive
-
Supplier Device Package:
10-TDFN-EP (3x3)
-
Package / Case:
10-WFDFN Exposed Pad
-
Frequency - Switching:
2MHz
-
Current - Output:
2.75A (Switch)
-
Part Status:
Active
-
Operating Temperature:
-40°C ~ 85°C (TA)
-
Output Type:
Adjustable (Fixed)
-
Series:
-
-
Voltage - Output (Max):
5V
-
Base Part Number:
MAX8815
-
Mounting Type:
Surface Mount
-
Synchronous Rectifier:
Yes
-
Voltage - Output (Min/Fixed):
3.3V (5V)
-
Packaging:
Cut Tape (CT)
-
Topology:
Boost
-
Manufacturer:
Maxim Integrated
-
detail:
Boost Switching Regulator IC Positive Adjustable (Fixed) 3.3V (5V) 1 Output 2.75A (Switch) 10-WFDFN Exposed Pad
