دیتاشیت MAX4741EUA+TGA5

MAX741-43

مشخصات دیتاشیت

نام دیتاشیت MAX741-43
حجم فایل 672.041 کیلوبایت
نوع فایل pdf
تعداد صفحات 12

دانلود دیتاشیت MAX741-43

MAX741-43 Datasheet

مشخصات

  • Multiplexer/Demultiplexer Circuit: 1:1
  • Part Status: Active
  • Charge Injection: 28pC
  • -3db Bandwidth: 100MHz
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Voltage - Supply, Dual (V±): -
  • Supplier Device Package: 8-uMAX
  • Package / Case: 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
  • Switch Time (Ton, Toff) (Max): 24ns, 16ns
  • Packaging: Tape & Reel (TR)
  • Channel-to-Channel Matching (ΔRon): 50mOhm
  • Voltage - Supply, Single (V+): 1.6V ~ 3.6V
  • Channel Capacitance (CS(off), CD(off)): 32pF, 32pF
  • Switch Circuit: SPST - NO
  • Mounting Type: Surface Mount
  • Series: -
  • Crosstalk: -110dB @ 1MHz
  • Number of Circuits: 2
  • Manufacturer: Maxim Integrated
  • Current - Leakage (IS(off)) (Max): 1nA
  • Base Part Number: MAX4741
  • On-State Resistance (Max): 800mOhm
  • detail: 2 Circuit IC Switch 1:1 800mOhm 8-uMAX
