دیتاشیت MAX4751EUD+TG35

MAX4751-53

مشخصات دیتاشیت

نام دیتاشیت MAX4751-53
حجم فایل 179.904 کیلوبایت
نوع فایل pdf
تعداد صفحات 11

دانلود دیتاشیت MAX4751-53

MAX4751-53 Datasheet

مشخصات

  • Multiplexer/Demultiplexer Circuit: 1:1
  • Part Status: Active
  • Charge Injection: 9pC
  • -3db Bandwidth: 250MHz
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Voltage - Supply, Dual (V±): -
  • Supplier Device Package: 14-TSSOP
  • Package / Case: 14-TSSOP (0.173", 4.40mm Width)
  • Switch Time (Ton, Toff) (Max): 85ns, 45ns
  • Packaging: Tape & Reel (TR)
  • Channel-to-Channel Matching (ΔRon): 30mOhm
  • Voltage - Supply, Single (V+): 1.6V ~ 3.6V
  • Channel Capacitance (CS(off), CD(off)): 20pF, 20pF
  • Switch Circuit: SPST - NO
  • Mounting Type: Surface Mount
  • Series: -
  • Crosstalk: -84dB @ 1MHz
  • Number of Circuits: 4
  • Manufacturer: Maxim Integrated
  • Current - Leakage (IS(off)) (Max): 100pA
  • Base Part Number: MAX4751
  • On-State Resistance (Max): 900mOhm
  • detail: 4 Circuit IC Switch 1:1 900mOhm 14-TSSOP
