دیتاشیت MAX4516CUK+TG075

MAX4516-17

مشخصات دیتاشیت

نام دیتاشیت MAX4516-17
حجم فایل 86.023 کیلوبایت
نوع فایل pdf
تعداد صفحات 8

دانلود دیتاشیت MAX4516-17

MAX4516-17 Datasheet

مشخصات

  • Multiplexer/Demultiplexer Circuit: 1:1
  • Part Status: Active
  • Charge Injection: 10pC
  • -3db Bandwidth: -
  • Operating Temperature: 0°C ~ 70°C (TA)
  • Voltage - Supply, Dual (V±): ±1V ~ 6V
  • Supplier Device Package: SOT-23-5
  • Package / Case: SC-74A, SOT-753
  • Switch Time (Ton, Toff) (Max): 100ns, 75ns
  • Packaging: Cut Tape (CT)
  • Channel-to-Channel Matching (ΔRon): -
  • Voltage - Supply, Single (V+): 2V ~ 12V
  • Channel Capacitance (CS(off), CD(off)): 9pF, 9pF
  • Switch Circuit: SPST - NO
  • Mounting Type: Surface Mount
  • Series: -
  • Crosstalk: -
  • Number of Circuits: 1
  • Manufacturer: Maxim Integrated
  • Current - Leakage (IS(off)) (Max): 1nA
  • Base Part Number: MAX4516
  • On-State Resistance (Max): 20Ohm
  • detail: 1 Circuit IC Switch 1:1 20Ohm SOT-23-5
