Part Numbering System Datasheet
Datasheet specifications
| Datasheet's name | Part Numbering System |
|---|---|
| File size | 107.748 KB |
| File type | |
| Number of pages | 7 |
Download Datasheet Part Numbering System |
Download Datasheet |
|---|
Other documentations
MAX1795-97 13 pages
Technical specifications
- Number of Outputs: 1
- Function: Step-Up
- Voltage - Input (Max): 5.5V
- Voltage - Input (Min): 1V
- Output Configuration: Positive
- Supplier Device Package: 8-uMAX
- Package / Case: 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
- Frequency - Switching: 500kHz
- Current - Output: 400mA (Switch)
- Part Status: Active
- Operating Temperature: -40°C ~ 85°C (TA)
- Output Type: Adjustable (Programmable)
- Series: -
- Voltage - Output (Max): 5.5V
- Base Part Number: MAX1796
- Mounting Type: Surface Mount
- Synchronous Rectifier: Yes
- Voltage - Output (Min/Fixed): 2V (3.3V, 5V)
- Packaging: Tube
- Topology: Boost
- Manufacturer: Maxim Integrated
- detail: Boost Switching Regulator IC Positive Adjustable (Programmable) 2V (3.3V, 5V) 1 Output 400mA (Switch) 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
