دیتاشیت MAX324ESA+G002
مشخصات دیتاشیت
| نام دیتاشیت |
MAX323-325
|
| حجم فایل |
108.112
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
12
|
مشخصات
-
Multiplexer/Demultiplexer Circuit:
1:1
-
Part Status:
Active
-
Charge Injection:
1pC
-
-3db Bandwidth:
-
-
Operating Temperature:
-40°C ~ 85°C (TA)
-
Voltage - Supply, Dual (V±):
-
-
Supplier Device Package:
8-SOIC
-
Package / Case:
8-SOIC (0.154", 3.90mm Width)
-
Switch Time (Ton, Toff) (Max):
150ns, 100ns
-
Packaging:
Tube
-
Channel-to-Channel Matching (ΔRon):
800mOhm
-
Voltage - Supply, Single (V+):
2.7V ~ 16V
-
Channel Capacitance (CS(off), CD(off)):
9pF, 9pF
-
Switch Circuit:
SPST - NC
-
Mounting Type:
Surface Mount
-
Series:
-
-
Crosstalk:
-85dB @ 1MHz
-
Number of Circuits:
2
-
Manufacturer:
Maxim Integrated
-
Current - Leakage (IS(off)) (Max):
100pA
-
Base Part Number:
MAX324
-
On-State Resistance (Max):
60Ohm
-
detail:
2 Circuit IC Switch 1:1 60Ohm 8-SOIC
