دیتاشیت MAX319ESA+TG002

MAX317-319

مشخصات دیتاشیت

نام دیتاشیت MAX317-319
حجم فایل 133.99 کیلوبایت
نوع فایل pdf
تعداد صفحات 12

دانلود دیتاشیت MAX317-319

MAX317-319 Datasheet

مشخصات

  • Multiplexer/Demultiplexer Circuit: 2:1
  • Part Status: Active
  • Charge Injection: 3pC
  • -3db Bandwidth: -
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Voltage - Supply, Dual (V±): ±4.5V ~ 20V
  • Supplier Device Package: 8-SOIC
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Switch Time (Ton, Toff) (Max): 175ns, 145ns
  • Packaging: Cut Tape (CT)
  • Channel-to-Channel Matching (ΔRon): 2Ohm (Max)
  • Voltage - Supply, Single (V+): 10V ~ 30V
  • Channel Capacitance (CS(off), CD(off)): 8pF, 8pF
  • Switch Circuit: SPDT
  • Mounting Type: Surface Mount
  • Series: -
  • Crosstalk: -85dB @ 1MHz
  • Number of Circuits: 1
  • Manufacturer: Maxim Integrated
  • Current - Leakage (IS(off)) (Max): 250pA
  • Base Part Number: MAX319
  • On-State Resistance (Max): 35Ohm
  • detail: 1 Circuit IC Switch 2:1 35Ohm 8-SOIC
