دیتاشیت NCV47701PDAJR2G
مشخصات دیتاشیت
| نام دیتاشیت |
NCV47701
|
| حجم فایل |
184.439
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
12
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
onsemi NCV47701PDAJR2G
-
Output Type:
Adjustable
-
Output Current:
350mA
-
Output Voltage:
5V~20V
-
Dropout Voltage:
500mV@(150mA)
-
Output Polarity:
Positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
40V
-
Operating Temperature:
-40°C~+150°C
-
Quiescent Current (Ground Current):
230uA
-
Power Supply Rejection Ratio (PSRR):
70dB@(100Hz)
-
Package:
SOP-8-EP
-
Manufacturer:
onsemi
-
Series:
Automotive, AEC-Q100
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Number of Regulators:
1
-
Voltage - Input (Max):
40V
-
Voltage - Output (Min/Fixed):
5V
-
Voltage - Output (Max):
20V
-
Voltage Dropout (Max):
0.5V @ 150mA
-
Current - Output:
350mA
-
Current - Quiescent (Iq):
230µA
-
Current - Supply (Max):
50mA
-
PSRR:
70dB (100Hz)
-
Control Features:
Enable
-
Protection Features:
Over Current, Over Temperature, Reverse Polarity
-
Mounting Type:
Surface Mount
-
Package / Case:
8-SOIC (0.154", 3.90mm Width)
-
Supplier Device Package:
8-SOIC
-
Base Part Number:
NCV47701
-
detail:
Linear Voltage Regulator IC 1 Output 350mA 8-SOIC
