SM12T1G دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | SM12T1G |
|---|---|
| حجم فایل | 46.486 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 4 |
دانلود دیتاشیت SM12T1G |
دانلود دیتاشیت |
|---|
سایر مستندات
SM05T1 Series, SZSM05T1G 5 pages
SM12T1G 7 pages
مشخصات فنی
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
- Polarity: Unidirectional
- Datasheet: onsemi SM12T1G
- Number of Lines: 2
- Clamping Voltage@Ipp: 19V
- Operating Temperature: -55°C~+150°C@(Tj)
- Breakdown Voltage (VBR): 13.3V
- Peak Pulse Power(Ppp)@8/20us: 300W
- Junction Capacitance(Cj)@1MHz: -
- Peak Pulse Current(Ipp)@8/20us: 12A
- Reverse Stand-Off Voltage (Vrwm): 12V
- Package: SOT-23(TO-236)
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Type: Zener
- Unidirectional Channels: 2
- Voltage - Reverse Standoff (Typ): 12V
- Voltage - Breakdown (Min): 13.3V
- Voltage - Clamping (Max) @ Ipp: 19V
- Current - Peak Pulse (10/1000µs): 12A (8/20µs)
- Power - Peak Pulse: 300W
- Power Line Protection: No
- Applications: General Purpose
- Capacitance @ Frequency: -
- Mounting Type: Surface Mount
- Package / Case: TO-236-3, SC-59, SOT-23-3
- Supplier Device Package: SOT-23-3 (TO-236)
- Base Part Number: SM12
- detail: 19V Clamp 12A (8/20µs) Ipp Tvs Diode Surface Mount SOT-23-3 (TO-236)
