دیتاشیت MJE13007G

MJE13007

مشخصات دیتاشیت

نام دیتاشیت MJE13007
حجم فایل 126.864 کیلوبایت
نوع فایل pdf
تعداد صفحات 10

دانلود دیتاشیت MJE13007

MJE13007 Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: SWITCHMODE™
  • Packaging: Tube
  • Part Status: Obsolete
  • Transistor Type: NPN
  • Current - Collector (Ic) (Max): 8A
  • Voltage - Collector Emitter Breakdown (Max): 400V
  • Vce Saturation (Max) @ Ib, Ic: 3V @ 2A, 8A
  • Current - Collector Cutoff (Max): 100µA
  • DC Current Gain (hFE) (Min) @ Ic, Vce: 5 @ 5A, 5V
  • Power - Max: 80W
  • Frequency - Transition: 14MHz
  • Operating Temperature: -65°C ~ 150°C (TJ)
  • Mounting Type: Through Hole
  • Package / Case: TO-220-3
  • Supplier Device Package: TO-220AB
  • Base Part Number: MJE13
  • detail: Bipolar (BJT) Transistor NPN 400V 8A 14MHz 80W Through Hole TO-220AB
