- دیتاشیت MJ11028,29,30,32,33
MJ11028,29,30,32,33 دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MJ11028,29,30,32,33 |
|---|---|
| حجم فایل | 118.905 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 4 |
دانلود دیتاشیت MJ11028,29,30,32,33 |
دانلود دیتاشیت |
|---|
سایر مستندات
MJ11033G 4 pages
مشخصات فنی
- RoHS: true
- Category: Triode/MOS Tube/Transistor/Darlington Transistors
- Datasheet: onsemi MJ11028G
- Transistor Type: NPN
- Operating Temperature: -55°C~+200°C@(Tj)
- Collector Current (Ic): 50A
- Power Dissipation (Pd): 300W
- Transition frequency (fT): -
- DC current gain (hFE@Vce,Ic): 1000@5V,25A
- Collector-emitter voltage (Vceo): 60V
- Collector cut-off current (Icbo@Vcb): 2mA
- Collector-emitter saturation voltage (VCE(sat)@Ic,Ib): 3.5V@50A,500mA
- Package: TO-204
- Manufacturer: onsemi
- Series: -
- Packaging: Tray
- Part Status: Active
- Current - Collector (Ic) (Max): 50A
- Voltage - Collector Emitter Breakdown (Max): 60V
- Vce Saturation (Max) @ Ib, Ic: 3.5V @ 500mA, 50A
- Current - Collector Cutoff (Max): 2mA
- DC Current Gain (hFE) (Min) @ Ic, Vce: 1000 @ 25A, 5V
- Power - Max: 300W
- Frequency - Transition: -
- Mounting Type: Through Hole
- Package / Case: TO-204AE
- Supplier Device Package: TO-3
- Base Part Number: MJ110
- detail: Bipolar (BJT) Transistor NPN - Darlington 60V 50A 300W Through Hole TO-3
