دیتاشیت FDFMA2P029Z

FDFMA2P029Z

مشخصات دیتاشیت

نام دیتاشیت FDFMA2P029Z
حجم فایل 500.748 کیلوبایت
نوع فایل pdf
تعداد صفحات 8

دانلود دیتاشیت FDFMA2P029Z

FDFMA2P029Z Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: PowerTrench®
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • FET Type: P-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 20V
  • Current - Continuous Drain (Id) @ 25°C: 3.1A (Ta)
  • Drive Voltage (Max Rds On, Min Rds On): 2.5V, 4.5V
  • Rds On (Max) @ Id, Vgs: 95mOhm @ 3.1A, 4.5V
  • Vgs(th) (Max) @ Id: 1.5V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 10nC @ 4.5V
  • Vgs (Max): ±12V
  • Input Capacitance (Ciss) (Max) @ Vds: 720pF @ 10V
  • FET Feature: Schottky Diode (Isolated)
  • Power Dissipation (Max): 1.4W (Tj)
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Surface Mount
  • Supplier Device Package: 6-MicroFET (2x2)
  • Package / Case: 6-VDFN Exposed Pad
  • Base Part Number: FDFMA2
  • detail: P-Channel 20V 3.1A (Ta) 1.4W (Tj) Surface Mount 6-MicroFET (2x2)
