دیتاشیت NJVMJD3055T4G

MJDxx55

مشخصات دیتاشیت

نام دیتاشیت MJDxx55
حجم فایل 192.368 کیلوبایت
نوع فایل pdf
تعداد صفحات 6

دانلود دیتاشیت MJDxx55

MJDxx55 Datasheet

مشخصات

  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Transistor Type: NPN
  • Current - Collector (Ic) (Max): 10A
  • Voltage - Collector Emitter Breakdown (Max): 60V
  • Vce Saturation (Max) @ Ib, Ic: 8V @ 3.3A, 10A
  • Current - Collector Cutoff (Max): 50µA
  • DC Current Gain (hFE) (Min) @ Ic, Vce: 20 @ 4A, 4V
  • Power - Max: 20W
  • Frequency - Transition: 2MHz
  • Operating Temperature: 150°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
  • Supplier Device Package: DPAK
  • Base Part Number: MJD305
  • detail: Bipolar (BJT) Transistor NPN 60V 10A 2MHz 20W Surface Mount DPAK
