دیتاشیت 2SJ661-DL-1E

2SJ661

مشخصات دیتاشیت

نام دیتاشیت 2SJ661
حجم فایل 378.689 کیلوبایت
نوع فایل pdf
تعداد صفحات 9

دانلود دیتاشیت 2SJ661

2SJ661 Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • FET Type: P-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 60V
  • Current - Continuous Drain (Id) @ 25°C: 38A (Ta)
  • Drive Voltage (Max Rds On, Min Rds On): 4V, 10V
  • Rds On (Max) @ Id, Vgs: 39mOhm @ 19A, 10V
  • Vgs(th) (Max) @ Id: -
  • Gate Charge (Qg) (Max) @ Vgs: 80nC @ 10V
  • Vgs (Max): ±20V
  • Input Capacitance (Ciss) (Max) @ Vds: 4360pF @ 20V
  • FET Feature: -
  • Power Dissipation (Max): 1.65W (Ta), 65W (Tc)
  • Operating Temperature: 150°C (TJ)
  • Mounting Type: Surface Mount
  • Supplier Device Package: TO-263-2
  • Package / Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
  • Base Part Number: 2SJ661
  • detail: P-Channel 60V 38A (Ta) 1.65W (Ta), 65W (Tc) Surface Mount TO-263-2
