دیتاشیت NJVMJD42CT4G-VF01

MJD41C, MJD42C

مشخصات دیتاشیت

نام دیتاشیت MJD41C, MJD42C
حجم فایل 86.054 کیلوبایت
نوع فایل pdf
تعداد صفحات 7

دانلود دیتاشیت MJD41C, MJD42C

MJD41C, MJD42C Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Obsolete
  • Transistor Type: PNP
  • Current - Collector (Ic) (Max): 6A
  • Voltage - Collector Emitter Breakdown (Max): 100V
  • Vce Saturation (Max) @ Ib, Ic: 1.5V @ 600mA, 6A
  • Current - Collector Cutoff (Max): 50µA
  • DC Current Gain (hFE) (Min) @ Ic, Vce: 15 @ 3A, 4V
  • Power - Max: 20W
  • Frequency - Transition: 3MHz
  • Operating Temperature: -65°C ~ 150°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
  • Supplier Device Package: DPAK
  • Base Part Number: MJD42
  • detail: Bipolar (BJT) Transistor PNP 100V 6A 3MHz 20W Surface Mount DPAK
