دیتاشیت 2SD1060R-1EX

2SD1060

مشخصات دیتاشیت

نام دیتاشیت 2SD1060
حجم فایل 197.42 کیلوبایت
نوع فایل pdf
تعداد صفحات 4

دانلود دیتاشیت 2SD1060

2SD1060 Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Tube
  • Part Status: Not For New Designs
  • Transistor Type: NPN
  • Current - Collector (Ic) (Max): 5A
  • Voltage - Collector Emitter Breakdown (Max): 50V
  • Vce Saturation (Max) @ Ib, Ic: 300mV @ 300mA, 3A
  • Current - Collector Cutoff (Max): 100µA (ICBO)
  • DC Current Gain (hFE) (Min) @ Ic, Vce: 100 @ 1A, 2V
  • Power - Max: 1.75W
  • Frequency - Transition: 30MHz
  • Operating Temperature: 150°C (TJ)
  • Mounting Type: Through Hole
  • Package / Case: TO-220-3
  • Supplier Device Package: TO-220-3
  • Base Part Number: 2SD1060
  • detail: Bipolar (BJT) Transistor NPN 50V 5A 30MHz 1.75W Through Hole TO-220-3
