- 2SA608N/2SC536N
2SA608NF-NPA-AT Datasheet
Datasheet specifications
| Datasheet's name | 2SA608N/2SC536N |
|---|---|
| File size | 267.818 KB |
| File type | |
| Number of pages | 6 |
Download Datasheet 2SA608N/2SC536N |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: ON Semiconductor
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Obsolete
- Transistor Type: PNP
- Current - Collector (Ic) (Max): 150mA
- Voltage - Collector Emitter Breakdown (Max): 50V
- Vce Saturation (Max) @ Ib, Ic: 300mV @ 10mA, 100mA
- Current - Collector Cutoff (Max): 100nA (ICBO)
- DC Current Gain (hFE) (Min) @ Ic, Vce: 160 @ 1mA, 6V
- Power - Max: 500mW
- Frequency - Transition: 200MHz
- Operating Temperature: 150°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
- Supplier Device Package: TO-226AA
- Base Part Number: 2SA608
- detail: Bipolar (BJT) Transistor PNP 50V 150mA 200MHz 500mW Through Hole TO-226AA
