دیتاشیت UA78M05CKVURG3
مشخصات دیتاشیت
| نام دیتاشیت | UA78M05,06,08,09,10,12,33 |
|---|---|
| حجم فایل | 1253.214 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 29 |
دانلود دیتاشیت UA78M05,06,08,09,10,12,33 |
UA78M05,06,08,09,10,12,33 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments UA78M05CKVURG3
- Output Current: 500mA
- Output Voltage: 5V
- Dropout Voltage: 2V@(350mA)
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 25V
- Operating Temperature: 0°C~+125°C
- Power Supply Rejection Ratio (PSRR): 80dB@(120Hz)
- Package: TO-252
- Manufacturer: Texas Instruments
- Number of Regulators: 1
- Base Part Number: UA78M
- Voltage - Input (Max): 25V
- Supplier Device Package: TO-252-3
- Voltage - Output (Max): -
- Packaging: Cut Tape (CT)
- Mounting Type: Surface Mount
- Protection Features: Over Current, Over Temperature, Short Circuit
- Control Features: -
- Voltage - Output (Min/Fixed): 5V
- Output Type: Fixed
- Voltage Dropout (Max): 2V @ 350mA
- Part Status: Active
- Series: -
- Current - Output: 500mA
- PSRR: 80dB (120Hz)
- Output Configuration: Positive
- Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- detail: Linear Voltage Regulator IC 1 Output 500mA TO-252-3
