دیتاشیت TS5A3359DCUR
مشخصات دیتاشیت
| نام دیتاشیت |
TS5A3359
|
| حجم فایل |
1418.868
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
36
|
مشخصات
-
RoHS:
true
-
Category:
Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
-
Datasheet:
Texas Instruments TS5A3359DCUR
-
Switch Circuit:
-
-
Package:
VSSOP-8
-
Manufacturer:
Texas Instruments
-
Channel Capacitance (CS(off), CD(off)):
18pF, 54pF
-
Channel-to-Channel Matching (ΔRon):
100mOhm
-
Operating Temperature:
-40°C ~ 85°C (TA)
-
Packaging:
Cut Tape (CT)
-
Multiplexer/Demultiplexer Circuit:
3:1
-
-3db Bandwidth:
75MHz
-
Charge Injection:
20pC
-
Current - Leakage (IS(off)) (Max):
20nA
-
On-State Resistance (Max):
900mOhm
-
Package / Case:
8-VFSOP (0.091", 2.30mm Width)
-
Voltage - Supply, Single (V+):
1.65V ~ 5.5V
-
Switch Time (Ton, Toff) (Max):
21ns, 10.5ns
-
Supplier Device Package:
8-VSSOP
-
Mounting Type:
Surface Mount
-
Base Part Number:
TS5A335
-
Voltage - Supply, Dual (V±):
-
-
Number of Circuits:
1
-
Crosstalk:
-64dB @ 1MHz
-
Part Status:
Active
-
Series:
-
-
detail:
1 Circuit IC Switch 3:1 900mOhm 8-VSSOP
