TS5A3359DCUR
در 0 فروشگاه قیمت هنوز مشخص نشده است
این محصول در حال حاضر فروشنده ای ندارد!
| Manufacturer | Texas Instruments |
| Package | 8-VFSOP (0.091", 2.30mm Width) |
| Datasheet | TS5A3359 |
| Description | 1 Circuit IC Switch 3:1 900mOhm 8-VSSOP |
فروشنده های TS5A3359DCUR
فروشگاهی یافت نشد
تغییرات قیمت
مشخصات TS5A3359DCUR
- RoHS true
- Category Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
- Datasheet Texas Instruments TS5A3359DCUR
- Switch Circuit -
- Package VSSOP-8
- Manufacturer Texas Instruments
- Channel Capacitance (CS(off), CD(off)) 18pF, 54pF
- Channel-to-Channel Matching (ΔRon) 100mOhm
- Operating Temperature -40°C ~ 85°C (TA)
- Packaging Cut Tape (CT)
- Multiplexer/Demultiplexer Circuit 3:1
- -3db Bandwidth 75MHz
- Charge Injection 20pC
- Current - Leakage (IS(off)) (Max) 20nA
- On-State Resistance (Max) 900mOhm
- Package / Case 8-VFSOP (0.091", 2.30mm Width)
- Voltage - Supply, Single (V+) 1.65V ~ 5.5V
- Switch Time (Ton, Toff) (Max) 21ns, 10.5ns
- Supplier Device Package 8-VSSOP
- Mounting Type Surface Mount
- Base Part Number TS5A335
- Voltage - Supply, Dual (V±) -
- Number of Circuits 1
- Crosstalk -64dB @ 1MHz
- Part Status Active
- Series -
- detail 1 Circuit IC Switch 3:1 900mOhm 8-VSSOP
