LM139,239,339(A), LM2901(AV,V) دیتاشیت

LM139,239,339(A), LM2901(AV,V)

مشخصات دیتاشیت

نام دیتاشیت LM139,239,339(A), LM2901(AV,V)
حجم فایل 1275.688 کیلوبایت
نوع فایل pdf
تعداد صفحات 33

دانلود دیتاشیت LM139,239,339(A), LM2901(AV,V)

دانلود دیتاشیت

سایر مستندات

LM339AN 36 pages

مشخصات فنی

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Comparators
  • Datasheet: Texas Instruments LM239ADR
  • Output Type: 开集;轨到轨
  • Supply Current: 2mA
  • Supply Voltage: 2V~30V;1V~15V
  • Number of Elements: 4
  • Operating Temperature: -25°C~+85°C
  • Input Bias Current (Ib): 0.25uA
  • Input Offset Voltage (Vos): 3mV
  • Input Hysteresis Voltage (Vhys): -
  • Common Mode Rejection Ratio (CMRR): -
  • Package: SOP-14
  • Manufacturer: Texas Instruments
  • Current - Output (Typ): 20mA
  • Part Status: Active
  • Mounting Type: Surface Mount
  • Package / Case: 14-SOIC (0.154", 3.90mm Width)
  • Hysteresis: -
  • Base Part Number: LM239
  • Voltage - Input Offset (Max): 3mV @ 30V
  • Series: -
  • Current - Quiescent (Max): 2mA
  • Type: Differential
  • Voltage - Supply, Single/Dual (±): 2V ~ 30V, ±1V ~ 15V
  • CMRR, PSRR (Typ): -
  • Current - Input Bias (Max): 0.25µA @ 5V
  • Packaging: Cut Tape (CT)
  • Propagation Delay (Max): -
  • Supplier Device Package: 14-SOIC
  • detail: Comparator Differential CMOS, MOS, Open-Collector, TTL 14-SOIC
