دیتاشیت STF31N65M5

STx31N65M5

مشخصات دیتاشیت

نام دیتاشیت STx31N65M5
حجم فایل 1153.875 کیلوبایت
نوع فایل pdf
تعداد صفحات 29

دانلود دیتاشیت STx31N65M5

STx31N65M5 Datasheet

مشخصات

  • Manufacturer: STMicroelectronics
  • Series: MDmesh™ V
  • Packaging: Tube
  • Part Status: Active
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 650V
  • Current - Continuous Drain (Id) @ 25°C: 22A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 148mOhm @ 11A, 10V
  • Vgs(th) (Max) @ Id: 5V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 45nC @ 10V
  • Vgs (Max): ±25V
  • Input Capacitance (Ciss) (Max) @ Vds: 816pF @ 100V
  • FET Feature: -
  • Power Dissipation (Max): 30W (Tc)
  • Operating Temperature: 150°C (TJ)
  • Mounting Type: Through Hole
  • Supplier Device Package: TO-220FP
  • Package / Case: TO-220-3 Full Pack
  • Base Part Number: STF31N
  • detail: N-Channel 650V 22A (Tc) 30W (Tc) Through Hole TO-220FP
