TN2540-600G-TR Datasheet
Datasheet specifications
| Datasheet's name | TN2540,TXN625,TYN625,825,1225 |
|---|---|
| File size | 207.404 KB |
| File type | |
| Number of pages | 11 |
Download Datasheet TN2540,TXN625,TYN625,825,1225 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: STMicroelectronics
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Voltage - Off State: 600V
- Voltage - Gate Trigger (Vgt) (Max): 1.3V
- Current - Gate Trigger (Igt) (Max): 40mA
- Voltage - On State (Vtm) (Max): 1.6V
- Current - On State (It (AV)) (Max): 16A
- Current - On State (It (RMS)) (Max): 25A
- Current - Hold (Ih) (Max): 50mA
- Current - Off State (Max): 5µA
- Current - Non Rep. Surge 50, 60Hz (Itsm): 300A, 314A
- SCR Type: Standard Recovery
- Operating Temperature: -40°C ~ 125°C
- Mounting Type: Surface Mount
- Package / Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Supplier Device Package: D²PAK
- Base Part Number: TN2540
- detail: SCR 600V 25A Standard Recovery Surface Mount D²PAK
